FPV Flight Controller Stack F405 80A with STM32F405 MCU and ICM 42688-P Gyro for Racing Drones

Product Categories

Kimpok Technology Co., Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: FPV Flight Controller Stack F405 80A with STM32F405 MCU and ICM 42688P Gyro for Racing Drones
Brand: KIMPOK
Price: 1 USD

Brand Name : KIMPOK

Model Number : ESC 60A 8S + F405 Flight Controller Combo

Certification : Cerfication

Place of Origin : China

MOQ : 3000

Price : negotiation

Payment Terms : L/C,T/T,Western Union

Supply Ability : 3000PIECES PER MONTH

Delivery Time : 5-8work days

Packaging Details : standard packing

Type : ESC 60A 8S + F405 Flight Controller Combo

MCU : STM32F405

IMU(Gyro) : ICM 42688-P

Barometer : Built-in

Black box : 16MB

BEC : 5V,10V

Dimension : 36*36*7.8mm

Mounting : 30.5*30.5mm (M3)

Input voltage : 3~6S

UART serial port : 6

ESC Firmware : 32bit

Contact Now

Product Description

Item	Description
Product	FPV Flight Controller Stack
Model Name	F405 80A Flight Control
Firmware	FLAOF405X8
MCU	STM32F405
IMU(Gyroscope)	ICM 42688-P
Input voltage	4-6S Lipo(14.8-26.1V)
BEC	5V/10V
barometer	Build-in
Black box	16MB
Size	36367.8mm
Installation hole distance	30.5mm*30.5mm
Weight	7g
UART serial port	6
Electronic speed control (ESC) parameters	Continuous current:80A Peak current:100A(8S) Supported batteries:3-8S Lipo ESC Firmware:32bit Supported protocols:Oneshot125/Oneshot42/Mulishot modes Dshot 150/300/600/1200
Place of Origin	Guangdong,China
